Specification
Specification
- CAPACITY5/8"
- CHUCK SIZE5/8"
- SWING18"
- MAX. DISTANCE CHUCK TO TABLE23-1/8"
- MAX. DISTANCE CHUCK TO BASE40-7/8"
- STROKE6"
- TABLE SIZE16-1/2" x 16-1/2"
- SPINDLE TAPERMT #2
- QUILL DIAMETER75 mm
- VARIABLE SPEED RANGE (OPTIONAL SETTING)50 - 3,000 RPM (3,000 - 5,500)
- MOTOR1.75 HP, 15 Amp.
- VOLTAGE120V, 60 Hz, 1 phase
- ASSEMBLED DIMENSIONS(LXWXH) / WEIGHT17-5/8" x 22-3/4" x 70-5/8" / 284 lbs
- PACKAGE DIMENSIONS(LXWXH) / WEIGHT62-3/4" x 27" x 17" / 325 lbs
- UPC7 72995 01544 3
